Long Autonomy 25kVA / 20kW Diesel Generator with 1000L Fuel Tank

E-mail

Extended Power, Unmatched Autonomy

Engineered for mission-critical reliability, this 25kVA diesel generator is designed specifically for remote locations and long-term backup scenarios. By integrating an industrial-grade 1000L oversized fuel tank, we have redefined "long autonomy," drastically reducing refueling frequency and operational downtime.

Key Features

Extreme Runtime: The high-capacity 1000L tank provides hundreds of hours of continuous operation at typical loads, making it the perfect "set-and-forget" solution for remote sites.
Industrial Precision: Powered by a high-efficiency diesel engine ensuring stable voltage output and superior transient response.
All-Weather Durability: Built with a heavy-duty, corrosion-resistant canopy designed to withstand harsh environments while maintaining low noise levels.
Smart Control: Equipped with a professional-grade digital controller for real-time monitoring of fuel levels, engine health, and power output.
Streamlined Maintenance: Thoughtfully designed access points for quick oil and filter changes, even in extended-run applications.

Ideal Applications

Telecommunication Base Stations
Off-grid Agricultural Facilities
Remote Construction Sites
Emergency Backup for Rural Infrastructure

Product Specifications

ltem	Value / القيمة	البند
Factory Model	AXY-20XC	طراز المصنع
Genset Prime Power	25KVA / 20KW	القدرة الساسية للمولد
Factory Date	2025-12-20	تاريخ التصنيع
Controller Pannel	SmartGen 6120N	لوحة التحكم
Engine Brand	FAWDE	علمة المحرك التجارية
Engine Model	4DW92-42D	طراز المحرك
Engine Prime Power	35KVA / 28KW	القدرة الساسية للمحرك
Engine Max Power	38.75KVA / 31KW	أقصى قدرة للمحرك
Rated Speed	1800RPM	السرعة المقدرة
Cylinder quantity	4	عدد السطوانات
Cylinder Arrangement	Vertical ln-line	ترتيب السطوانات
Aspiration	Naturally Aspirated	نظام السحب
Bore x Stroke	90mm x 100mm	القطر × الشوط
Displacement	2.54L	الزاحة
Compression Ratio	17:1	نسبة الضغط
Type lnjection System	Direct lnjection	نوع نظام حقن الوقود
Speed Adjustment Method	Mechanical Governor	طريقة تنظيم السرعة
Total Lubrication System Capacity	8L	إجمالي سعة نظام التشحيم
Fuel Consumption at 50% load	~4.1L/h	استهلك الوقود عند حمل 50%
Alternator Brand	LEROY-SMOER	علمة المنوب التجارية
Alternator Model	TAL-A42-CJ6S/4	طراز المنوب
Rated Voltage	400V / 230V	الجهد المقدر
Frequency	60HZ	التردد
Power Factor	0.8	معامل القدرة
Alternator Enclosure	lP23	درجة حماية المنوب
Circuit Breaker Brand	ABB	علمة قاطع الدورة
AMPS	32A	التيار أمبير
Phase	Three-Phase Four-Wire	الطوار
Fuel Tank	1000L	خزان الوقود
Dimensions	2150mm x 900mm x 2150mm	البعاد
Weight (approx.)	~1.5tons	الوزن تقريببا
